PTFE Products

Made of 100% pure PTFE, these PTFE products are an effective replacement for PTFE impregnated asbestos packing. Superior in quality and strength, these products are self-lubricating, non-toxic, flexible in nature and can be used against corrosive chemicals, solvents, oils, petroleum-by products and oxygen service, pumps and valves. Our range of PTFE packaging solutions include - PTFE bellows for lined pipes, PTFE moulded products, PTFE machined products, PTFE rods, PTFE bushes, PTFE tubes and PTFE sheets.

We manufacture and supply superior quality PTFE bellows for packaging of lined pipes. Specially designed from Virgin P.T.F.E., these are contour moulded. The streamlined manufacturing process ensures an excellent structure of the material, durability and low maintenance costs.

Our range of PTFE bellows serve for the compensation of :

Vibration Thermal Strain and Expansion Axial and Radial motion

and are designed for resisting highly corrosive chemicals plants and pipings for aggressive medias.

We produce these ptfe bellows in different size ranges from NB 25 mm to NB 500 mm, which can be used upto 2000 C. The allowable operating pressures depends on service conditions.

Installed in PTFE Lined Carbon Steel Piping and equipment without additional gaskets, Our bellows are suitable for usages in piping and equipment made of glass, enamels and ceramics. The sealing surfaces are covered and end plates are individually boxed to ensure protection against mechanical damage. Limit bolts are preset to prevent over extension during the operation.

Specifications:

We manufacture and supply superior quality PTFE moulded products, PTFE machined products and PTFE soft unsintered products for various applications.

The importance of PTFE machined & moulded products becomes more important as it is often more efficient to use moulded semi-finished products to avoid excessive machining of relatively expensive materials and for reducing the machining labour and time. The tooling costs are normally very low.

We offer these PTFE products in two forms viz milled form and slit form. Milled type envelope is a better method as it is made to fit the insert and presents a flat face to tee flange. The Slit type is perfectly adequate for applications where cost is considered a major factor. The envelop in this type does not present a full face to the flange.

Solid Gaskets can also be made in different types of shapes and sizes on request.

Specifications:

These gaskets are widely used for applications in chemical plants, glass/glass lined equipment due to their high temperature, corrosion and durability. Envelope Gaskets are produced in two forms viz. milled and slit forms.

We also offer high quality PTFE rods, bushes, PTFE tubes and PTFE sheets for different requirements of our clients. Superior in quality, these products are known for their durability and performance and are available with following specifications.

Bushes Specifications:

O.D : 32-150mm (standard) I.D : 12.5-127mm (standard) Length : 100mm (standard) upto 300mm in special cases We can also supply larger sizes on request

Rods Specifications:

Dia : 3-250 (standard) Length : 300-900mm (standard)

PTFE Sheets Specifications:

Sizes available : 300 x 300mm to 900 x 900mm Thickness : 3-25mm Thickness sheets available on request PTFE-Filler also

PTFE Thin Sheets Specifications:

Width : 300-600mm Thickness : 0.1-3.0mm Thin sheets are available in roll form or cut to length form. Available in roll form or length cut to request.

Fillers Specifications:
glass/carbon/graphite/bronze+MoS2.
